ClearPath All-in-One Servo Motors

ClearPath integrates all servo components into one compact package:

Motion controller
Brushless, permanent magnet motor
High-resolution encoder
Digital servo drive electronics
3-year warranty

ClearPath integrated servo motors showing a range of NEMA 23 NEMA 34 and NEMA 56 sizes

Choose a Motor Control Series

Compare All
Control Series

ClearPath Motor Selection Guide

If you need help selecting the right ClearPath motor, use this guide to narrow your options in 3 easy steps.

Choose your series, model, and power range
Get a list of relevant specs and pricing
Compare ClearPath models side-by-side

ClearPath Accessories Guide

For help with selecting accessories for your specific ClearPath system, use this walkthrough.

Step-by-step guide to select recommended and optional accessories
Comprehensive overview video for each accessory
Use the interactive accessories schematics to easily purchase the parts you need

ClearPath Motor Specs & Pricing

For engineers that already know their ClearPath series and exact requirements:

See specs and pricing for 1000+ part numbers
Filter by torque, speed, power, voltage, frame size, length, and more
Overlay torque vs. speed curves and compare specs and pricing

ClearPath Part Number Index/Search

If you already know your part number(s), use the index to quickly find:

Pricing and ordering of ClearPath motors or accessories
Specifications (including torque vs. speed curves)
Drawings, manuals, or setup software

Overview

Motor Selection Guide

Hudson BLDC Servo Motors

Teknic's Hudson servo motors are designed to excel in the most demanding OEM applications.

Reduce motor footprint and maximize power output with optimized magnet shape, motor skew, and rotor geometry
Improve machine reliability with a brushless servo motor designed with oversized bearings and class H windings
Increase machine performance with Hudson's high torque density and fast electrical time constant
Buy online, starting at $214
3-year warranty

Product Overview

Specs and Pricing

Meridian Integrated Controllers

Meridian is an integrated motion controller and digital servo drive that is capable of controlling servos, linear motors, and steppers.

Reduce machine vibration and increase throughput with g-Stop™ anti-resonance
Use the Accelerated Prototyping System™ to diagnose performance issues and reduce development time
Improve stepper motor smoothness and increase power output with vector sinewave commutation
Get up and running quickly with the sFoundation source code library
3-year warranty

Product Overview

Eclipse Digital Servo Drives

Eclipse is a state-of-the-art digital brushless servo drive capable of controlling brushed and brushless servo motors.

RAS motion smoothing algorithm reduces move and settling time, noise, and mechanical wear
Teknic's proprietary servo algorithms eliminate overshoot and improve machine performance
Quickset digital oscilloscope and move generator reduce development time
3-year warranty

Product Overview

Motor Brakes

Spring applied power-off (or fail-safe) brakes are used in applications that require the axis to stay in position, even if the machine loses power or is turned off. Brakes are a great option for vertical applications or when additional safety measures are required.

Front mount compatible with any NEMA 23 or NEMA 34 motor frames
24 VDC input for easy actuation
NEMA 23 brakes start at $245
NEMA 34 brakes start at $327
Buy Online; 90-day satisfaction guarantee
3-year warranty

Product Overview

Planetary Gearboxes

Teknic's planetary gearboxes are an effective solution to dramatically increase the torque output of a motor, among other key benefits.

Compatible with any NEMA 17, 23, 34, 56 or 143 motor
Increase motor load handling
Offloads motor bearings, allowing for increased axial/radial loading
Compact design is ideal for space-constrained applications
Buy Online; 90-day satisfaction guarantee

Product Overview

IPC DC Power Supplies

The Amazon™ Intelligent Power Center (IPC) is designed and built specifically for motion control applications.

High output capacitance and built-in regen control system prevents over-voltage shutdowns and the need for external regeneration control and load resistor
High peak power drastically reduces power supply droop during motor acceleration
Buy online, starting at $202
Built in the USA; 3-year warranty

Product Overview

ClearCore I/O and Motion Controllers

ClearCore is a controller platform for industrial I/O and motion control.

Control 4 steppers or digital servos like ClearPath
Analog/digital inputs and outputs; 24V industrial quality
Rich C++ library with dozens of example programs
Ethernet and serial communication
Buy online; 90-day satisfaction guarantee; 3-year warranty

Product Overview

Specs and Pricing

ClearLink EtherNet/IP Motion and I/O Controller

ClearLink is an industrial I/O and motion controller, compatible with any EtherNet/IP scanner.

Control 4 steppers or digital servos like ClearPath
Configurable analog/digital inputs and outputs; 24V industrial quality
Rich EDS file support reduces development time
Add up to an additional 64 digital I/O points
Buy online; 90-day satisfaction guarantee; 3-year warranty

Product Overview

Specs and Pricing

Teknic Legacy Products

Teknic continues to advance the state-of-the-art in servo motion control. As a result, new products are engineered to provide greater performance, reliability, and value. Products that are eventually displaced by the introduction of new technology are not simply discontinued—the components continue to be manufactured and supported for as long as parts are reasonably available.

When products are forced into end of life, Teknic's factory engineers work with customers who desire to extend the life of their legacy machines with newer servo components. Some of Teknic's legacy products were available for nearly 30 years before they moved to end of life status.

Product Overview

Support
Downloads
About

IPC-5

350/500 Watt DC Power Supply

Part Number: IPC-5
Output: 75 VDC, 350 W cont. (500 W fan-cooled), 900 W peak
Input: 108-250 VAC
Connectors: 8-pin Molex Mini-fit (input) and 2-pin Sabre (output)
Dimensions, in (mm): 7.20 (183) x 5.20 (132) x 2.26 (57.3)
Weight, lbs (kg): 2.25 (1.02)
Certifications: UL, CE
More

Low Voltage (75 VDC) "Intelligent Power Center" power supply optimized for motor drive bus power. Compatible with ClearPath NEMA 23 and 34 integrated servos, and Eclipse and Meridian 2xx-5xx series products.

IPC-3/5 User Manual

3D Drawings

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$253	Register for Volume Pricing			CONTACT

IPC-5	See pricing above			Add to cart
IPC35-CABLE110 110VAC line cord	$14			Add to cart

The "Add to Cart" button will add one of each component (power supply and cable) unless you edit the quantities. Type "0" for the quantity of any component you don't want to add to your cart.

IPC-5	IPC35-CABLE110 110VAC line cord
See pricing above	$14



Add to cart
The "Add to Cart" button will add one of each component (power supply and cable) unless you edit the quantities. Type "0" for the quantity of any component you don't want to add to your cart.

IPC-3

225 Watt DC Power Supply

Part Number: IPC-3
Output: 75 VDC, 225 W cont., 900 W peak
Input: 108-250 VAC
Connectors: 8-pin Molex Mini-fit (input) and 2-pin Sabre (output)
Dimensions, in (mm): 7.13 (181) x 5.20 (132) x 2.26 (57.3)
Weight, lbs (kg): 2.11 (0.96)
Certifications: UL, CE
More

IPC-3/5 User Manual

3D Drawings

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$202	Register for Volume Pricing			CONTACT

IPC-3	See pricing above			Add to cart
IPC35-CABLE110 110VAC line cord	$14			Add to cart

The "Add to Cart" button will add one of each component (power supply and cable) unless you edit the quantities. Type "0" for the quantity of any component you don't want to add to your cart.

IPC-3	IPC35-CABLE110 110VAC line cord
See pricing above	$14



Add to cart
The "Add to Cart" button will add one of each component (power supply and cable) unless you edit the quantities. Type "0" for the quantity of any component you don't want to add to your cart.

IPC35-CABLE110

AC Power Cable for IPC-3 and IPC-5

Part Number: IPC35-CABLE110
Connectors: 8-pin Molex Mini-fit to U.S. standard 3-prong 120V AC plug (NEMA 5-15)
Length: 1.98 m (6.5 ft)

AC Power (120VAC) Cable for IPC-3 and IPC-5 motor drive power supplies.

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$14	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

POWER4-STRIP

DC Bus Distribution Strip

Part Number: POWER4-STRIP
Input: Input: Bus power, 24-75 VDC (nominal)
Output: Distributes the applied input voltages
Connectors: Bus Power: 2-pin Sabre (Input x1, Output x 5)
Dimensions, in (mm): 3.6 x 2.4 (91.9 x 59.7)
Certifications: UL recognized, cUL recognized, CE

Distributes DC bus power to up to five ClearPath motors. Requires 24-75 VDC bus power supply.

2D Drawing

3D Drawings

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$37	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

PC-SBR-72

DC Power Cable, IPC to POWER4-HUB, 6 ft

Part Number: PC-SBR-72
Connectors: Main Bus Input: 2-pin Sabre; Main Bus Output: 2-pin Sabre
Length: 1.83 meters (6 ft)

Cable used to supply 75 volt bus power from an IPC-5 or IPC-3 to a ClearPath power distribution board (POWER4-HUB, POWER4-HUB-S, POWER4-STRIP, and POWER4-STRIP-S) or to daisy-chain multiple power distribution boards.

2D Drawing

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$21	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

POWER4-HUB

DC Power Distribution Hub

Part Number: POWER4-HUB
Input: Bus Power: 24-75 VDC (nominal); Logic Power: 15-30 VDC
Output: Distributes the applied input voltages
Connectors: Bus Power: 2-pin Sabre; Logic Power: 2-pin Molex MiniFit Jr.
Dimensions, in (mm): 3.06 x 4.12 (77.7 x 104.7)
Certifications: UL recognized, cUL recognized, CE

Distributes DC bus power to up to four ClearPath motors. Requires 24 volt power to operate (in addition to bus power). The Power Hub also acts as logic power backup for the motors, i.e., the motors will still retain encoder position and communication ability even with bus power removed (for safety during an E-stop, for example). With logic power backup active, users can avoid rehoming their motors.

2D Drawing

3D Drawings

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$52	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

CPM-CABLE-M2P2P-120

24 Volt Power, 2-Pin Molex Cable

Part Number: CPM-CABLE-M2P2P-120
Connectors: 2-pin Molex to 2-pin Molex
Length: 3.05 m (10 ft)

Logic power cable compatible with several Teknic power distribution breakout & accessory boards including the SC4-HUB, POWER4-HUB, POWER4-HUB-S, and the ASU-FR510. This cable can also be used to daisy-chain power between boards or it can be cut to length for flying lead termination at the logic power supply.

2D Drawing

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$14	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

PWR-IO-24VDC

24 VDC Power Supply

Part Number: PWR-IO-24VDC
Output Voltage: 24 VDC
Output Current: 6.5 Amps
Input Voltage: 85-264 VAC, auto-selected
Dimensions: 159x97x30mm (6.26x3.82x1.18 in.)

General-purpose, 156-watt, logic power supply; can be used to power your IO-HUBs, Brakes, and ClearPath motor logic power backup through a POWER4-HUB.

Protection: Short circuit / Overload / Over-voltage / Over-temperature. Compliance with UL62368-1, EN61558-1/2-16. Operating temperature -25 to 50 deg. C with no derating.

3D Drawings

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$42	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

CPM-CABLE-PWR-MS120

DC Power Cable, IPC to ClearPath, 10 ft

Part Number: CPM-CABLE-PWR-MS120
Connectors: 4-pin Molex Mini-fit to 2-pin Sabre
Length: 3.05 m (10 ft)

Cable used to supply bus power from a DC power supply to a ClearPath motor. The Molex end connects to the ClearPath motor; the Sabre end connects directly to a Teknic IPC-5 or IPC-3 power supply, or to a or POWER4-HUB power distribution hub, but can be cut off if you intend to wire it to another supply.

2D Drawing

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$21	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

CPM-CABLE-PWR-MM660

DC Power Cable, IPC to ClearPath, 55 ft

Part Number: CPM-CABLE-PWR-MM660
Connectors: 4-pin Molex Mini-fit to 4-pin Molex Mini-fit
Length: 16.775 m (55 ft)

Cable used to supply bus power from a DC power supply to a ClearPath motor. It has ClearPath power connectors on both ends, so it is designed to be cut to make two shorter cables or one long cable, with flying leads at one end. See the IPC user manual for connector and mating component part numbers. (Note: this is only a 2-wire cable, so it is not suitable for use as the analog input cable on an ASU-FR510.)

2D Drawing

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$107	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

CLCR-4-13

ClearCore Controller

Part Number: CLCR-4-13

Each ClearCore Industrial I/O and Motion Controller handles up to 4 axes of high-speed step & direction motion, and provides 13 software-configurable I/O points (fully protected and 24 VDC compatible). An extensive C++ Motion and I/O Library makes coding easier and more productive.

Specs & Pricing

Qty 1-9	10-49	50-99	100-199	200-319	320-999	1000+
$105 ~~$155~~	$105 ~~$130~~	$105 ~~$116~~	$105	$102	$99	CONTACT

Product Overview
Specs and Accessories

CLNK-4-13

ClearLink EtherNet/IP Motion & I/O Controller

Part Number: CLNK-4-13

ClearLink EtherNet/IP Industrial I/O and Motion Controller. 4 axes of step & direction output; 13 configurable I/O points (24 VDC compatible); 1 serial port and 1 I/O expansion port.

Specs & Pricing

Qty 1-9	10-49	50-99	100-199	200-319	320-999	1000+
$251	Register for Volume Pricing					CONTACT

Product Overview
Specs and Accessories

CPM-CABLE-CTRL-MU120

Controller Cable, 10 ft

Part Number: CPM-CABLE-CTRL-MU120
Connectors: 8-pin Molex Mini-fit to 8-pin Molex Mini-fit (one connector is overmolded)
Length: 3.05 m (10 ft)

This cable connects your ClearPath-IP motor and I/O Hub. The overmolded Molex connector connects to the motor, and the other end is plugged into your I/O Hub.

2D Drawing

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$26	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

CPM-CABLE-CTRL-MM660

Controller Cable, 55 ft

Part Number: CPM-CABLE-CTRL-MM660
Connectors: 8-pin Molex Mini-fit to 8-pin Molex Mini-fit
Length: 16.775 m (55 ft)

This cable connects your ClearPath-IP motor and I/O Hub. This cable comes with overmolded Molex Mini-Fit Jr. connectors on both ends, and designed to be modified (cut to length). You'll need to terminate the cut end with a Molex Mini-Fit Jr. connector to plug into the I/O Hub—see the manual for more information on connector, pin, and crimp tool part numbers.

2D Drawing

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$120	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

IO-HUB

ClearPath-IP I/O & Motor Hub

Dimensions, in (mm): 5.0 (127) x 3.5 (88.9) x 1.0 (25.4)
Weight, lbs (g): 0.40 (181)
Certifications: CE, RoHS

Available in three different functional configurations, the IO-HUB-2-R, IO-HUB-4-R, and IO-HUB-4-E motor hubs are required to connect ClearPath-IP motors to an EtherNet/IP scanner. See below for a comparison.

2D Drawing

3D Drawings

Choose an IO-HUB Model

Review specs and pricing to fit your application

P/N: IO-HUB-	2-R	4-R	4-E
Motion Axes	2	4	4
IP-Sync™
Motion-Specific I/O
Two EtherNet/IP Ports
GPIO
Analog Inputs
Analog Output
Encoder Input
PWM Outputs
Price (qty. 1-9)	$69	$99	$249

Detailed Comparison

Volume Pricing

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199
--	--	--	--
$69	Register for Volume Pricing
$99	Register for Volume Pricing
$249	Register for Volume Pricing

	CC-3TERM-PLUG-10PC Terminal block plugs
See pricing above	$11



Add to cart
The "Add to Cart" button will add one of each component (IO-HUB and terminal block plugs) unless you edit the quantities. Type "0" for the quantity of any component you don't want to add to your cart.

MPC023-24-001-T

NEMA 23 Power-Off Brake

Part Number: MPC023-24-001-T
Voltage Requirement: 24 VDC
Current Draw: 0.31 Amps
Output Torque: 0.5 Nm holding torque
Max Input Speed: 6000 RPM
Input Shaft Diameter: 0.375in
More

24V Spring-applied, power-off brake compatible with NEMA 23 ClearPath motors. One of the most common applications for power-off brakes is on "z-axis" (vertically oriented) mechanical assemblies. Without a brake, highly efficient, backdrivable mechanics will generally fall or crash due to gravity when the motor's power stage is turned off or disabled for any reason.

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$245	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

MPC034-24-003-T

NEMA 34 Power-Off Brake

Part Number: MPC034-24-003-T
Voltage Requirement: 24 VDC
Current Draw: 0.41 Amps
Output Torque: 1.68 Nm holding torque
Max Input Speed: 6000 RPM
Input Shaft Diameter: 0.50in
More

24V Spring-applied, power-off brake compatible with NEMA 34 ClearPath motors. One of the most common applications for power-off brakes is on "z-axis" (vertically oriented) mechanical assemblies. Without a brake, highly efficient, backdrivable mechanics will generally fall or crash due to gravity when the motor's power stage is turned off or disabled for any reason.

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$327	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

CABLE-CAT5-120

Controller Cable, 10 ft

Part Number: CABLE-CAT5-120
Connectors: 2x RJ45
Length: 3.05 m (10 ft)

Cat5e cable used to connect an IO-HUB with an EtherNet/IP master, or another EtherNet/IP device (including another IO-HUB). A flexible, snag-free, cable boot protects the plug while making it easy to depress the locking clip. 50μm gold-plated contacts.

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$9	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

CPM-CABLE-USB-120AB

USB Cable, SC4-HUB to USB Port

Part Number: CPM-CABLE-USB-120AB
Connectors: USB 2.0 A to B
Length: 3.05 meters (10 ft)

Cable used to connect your PC to an I/O Hub for setup and diagnostics. Once configured, the HUB is disconnected from the PC, so you only need one of these cables no matter how many I/O Hubs you buy.

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$9	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

CPM-CABLE-USB-120

USB Cable

Part Number: CPM-CABLE-USB-120
Connectors: USB 2.0 A to Micro-B
Length: 3.05 meters (10 ft)

Cable used to connect your PC to a ClearPath-IP motor for setup and diagnostics. Once configured, the motor is disconnected from the PC, so you only need one of these cables no matter how many ClearPath motors you buy.

Purchase

Qty 1-9	Qty 10-49	Qty 50-99	Qty 100-199	Qty 200+
$9	Register for Volume Pricing			CONTACT

Quantity

Add to cart

Quantities up to 5 generally ship within 3 business days.

ClearPath-IP Accessories Guide

How to Choose Your Accessories

DC Power Supply & AC Power Cable

24-75VDC is required for ClearPath bus power. Teknic recommends 75VDC for maximum motor power.
ClearPath can run from power supplies up to 90VDC, but will protectively shutdown at 94VDC, so a 75VDC power supply gives you better design margin in this regard.
The Teknic IPC-3 and IPC-5 power supplies are designed specifically for the unique requirements of servo control- they smoothly handle regenerated energy and large peak loads. See our article for further technical details & architectural comparisons.
One IPC power supply can typically power up to 6 ClearPath motors (application dependent - see FAQs and/or Accessories video).

		Learn More & Order
	350/500 Watt DC Power Supply IPC-5	Info / Order
	225 Watt DC Power Supply IPC-3	Info / Order
	AC Power Cable for IPC-3 and IPC-5 IPC35-CABLE110	Info / Order

Power Distribution Strip

Logic Power Backup Shown:

The POWER4-STRIP is an optional, 6-port breakout board/terminal block that distributes the main motor power for up to five ClearPath motors.
One of the six 2-pin Sabre connectors would function as the input connector for power from the Main Motor Power Supply (24 - 75 Vdc is required) while the remaining five connectors would provide output power to any attached ClearPath motors.
Use the Power Distribution Cable (PC-SBR-72) to connect the IPC-5 power supply with the POWER4-STRIP.
This breakout board option is generally appropriate for machines with more than 2 motors that don't require logic power backup. Note that the IPC-5 power supply natively has two motor power connectors so up to 2 motors can be directly connected to the IPC-5 without the breakout board.

Accessories without Logic Power Backup

		Learn More & Order
	DC Bus Distribution Strip POWER4-STRIP	Info / Order
	DC Power Cable, 6 ft PC-SBR-72	Info / Order

Power Distribution Hub & Cables

Logic Power Backup Shown:

The POWER4-HUB is an optional 4 port breakout board that distributes main DC bus power for up to 4 ClearPath motors and also provides logic power backup. With logic power backup, if bus power is removed (e.g., upon an E-stop), ClearPath will still communicate and monitor its position. So, upon restoring bus power, ClearPath can automatically return to its last commanded position.
The POWER4-HUB requires 24VDC (in addition to main motor bus power). Use the CPM-CABLE-M2P2P-120 cable to route 24VDC to the POWER4-HUB.
Use the Power Distribution Cable (PC-SBR-72) to connect the IPC-5 power supply with the POWER4-HUB.

Accessories with Logic Power Backup

		Learn More & Order
	DC Power Distribution Hub POWER4-HUB	Info / Order
	DC Power Cable, 6 ft PC-SBR-72	Info / Order
	24 Volt Power, 2-Pin Molex Cable CPM-CABLE-M2P2P-120	Info / Order
	24 VDC Power Supply PWR-IO-24VDC	Info / Order

Motor Power Cable

DC Power Cable

This cable connects DC bus power directly to a ClearPath motor from either the Main Motor Power Supply (e.g. IPC-5), the POWER4-HUB, or the POWER4-STRIP Power Distribution Boards.
The Motor Power Cable requires a 4-pin Molex Mini-fit Jr. connector on the ClearPath end and a 2-pin Sabre connector on the DC power supply end (if using a Teknic IPC-5 power supply or a POWER4-STRIP/HUB power distribution board).
Teknic offers a plug-and-play 10 foot cable and a 55 foot cable option, or cables can be manufactured with the proper materials and assembly tools.

		Learn More & Order
	DC Power Cable, 10 ft CPM-CABLE-PWR-MS120	Info / Order
	DC Power Cable, 55 ft CPM-CABLE-PWR-MM660	Info / Order

I/O Hub

ClearPath-IP motors use 2-axis and 4-axis sync hubs to simplify wiring and synchronize motors with sub-200-nanosecond precision. These hubs also make it easy to wire up home sensors, limit switches, and other motion-specific I/O to your ClearPath-IP motors. When upgraded to an I/O-HUB, customers can (in addition to retaining the sync hub functionality) configure the inputs to be general-purpose digital or analog inputs, and gain access to additional features, such as an external encoder input, an analog output, and more. Choose from one of three different versions (click below to learn more).

		Learn More & Order
	ClearPath-IP Hub I/O-HUB	Info / Order
	EtherNet/IP Network Cable, 10 ft CABLE-CAT5-120	Info / Order
	24 VDC Power Supply PWR-IO-24VDC	Info / Order

Controller Cable

This cable connects your ClearPath-IP motor to your I/O Hub.
The controller cable requires an 8-pin Molex Mini-fit connector on both ends and can be ordered directly from Teknic.
The 55' version is designed to be cut to length and turned into two cables (learn more below).

		Learn More & Order
	Controller Cable, 10 ft CPM-CABLE-CTRL-MU120	Info / Order
	Controller Cable, 55 ft CPM-CABLE-CTRL-MM660	Info / Order

Planetary Gearboxes

Planetary gearboxes reduce reflected load inertia, amplify motor output torque, isolate axial/radial loading from motor, and improve commanded resolution.
Mechanical compatibility with ClearPath and Hudson servo motors.

		Learn More & Order
	Gearboxes 600+ Models	Info / Order

Spring Applied, Power-Off Brakes

Power-off (or fail-safe) brakes are used in applications that require the axis to stay in position, even if the machine loses power or is turned off (this is common for vertical applications or when additional safety measures are required).
Apply 24V to disengage the brake and allow motion.

		Learn More & Order
	NEMA23 Brake MPC023-24-001-T	Info / Order
	NEMA34 Brake MPC034-24-003-T	Info / Order
	24 VDC Power Supply PWR-IO-24VDC	Info / Order

USB Setup Cable

To configure a ClearPath-IP system, customers need to configure both the motor and the I/O Hub.
The USB Type-A to Type-Micro-B cable connects a Windows PC to the USB port on the rear of ClearPath-IP motor body for initial motor setup and diagnostics using the ClearPath ClearView Software. Using the same software, customers connect a USB Type-A to Type-B cable to an I/O Hub to configure it.
After setup, these cables are typically disconnected for normal application operation (but they can be used for diagnostic purposes).
These cables can be purchased from Teknic or third parties. The USB cables should be "fully rated" cables (shielded and designed for high-speed communication—not a charging cable—which can be true of USB Type-A to Type-Micro-B cables in particular).

		Learn More & Order
	USB Cable CPM-CABLE-USB-120	Info / Order
	USB Cable CPM-CABLE-USB-120AB	Info / Order

ClearView Software

This setup software is used to manually control and configure ClearPath-IP motors.
ClearView provides simple, but powerful diagnostic tools to measure the performance of your motors and mechanics.
You can download ClearView from Teknic for free.

		Learn More & Download
	ClearView Software CPM-CLEARVIEW	Info / Order

IP Series

IP53

Watch the Step-by-Step Guide

Next Power Supplies Next My Cart

Feature	Description	IO-HUB-2-R	IO-HUB-4-R	IO-HUB-4-E
Number of motion control axes	Easily connect multiple ClearPath-IP motors to your EtherNet/IP Scanner.	2	4	4
IP-Sync™ compatible	Most EtherNet/IP™ networks update in the millisecond range. ClearPath-IP motors can achieve sub-200-nanosecond synchronization with IP-Sync™ technology.
Motion-specific I/O	13 points of I/O configurable for use with Home Sensors, Limit Switches, Position Capture Inputs, Stop Sensor Inputs, and Brake Outputs. Compatible with NPN & PNP devices.
Two EtherNet/IP Ports	Built-in two-port Ethernet switch to easily daisy chain multiple hubs or 3rd party EtherNet/IP devices.
I/O configurable as GPIO	Configure any unused Motion-specific I/O as general purpose Inputs or Outputs for use by your PLC Master.
Analog Inputs	All inputs can be configured to run with 0-10V, or 4-20mA analog inputs (e.g., potentiometers, transducers, etc.).
Analog Output	Configure one output as a 0-10V, or 4-20mA analog output.
Encoder Input	Compattable with external encoders that output balanced RS-422 (differential) signals on A, B, and I.
PWM outputs	Configure any output to generate a PWM signal to run DC Fans / motors, LEDs, or other devices.

ClearPath-IP Accessories Guide

Lead Time/Shipping Info
